G12r N-type Topcon Flexible Solar Module
| Parameter | Specification |
|---|---|
| Cell Type | G12R N-Type TOPCon |
| Cell Dimensions | 182.3 × 105 mm |
| Number of Cells | 36 |
| Cell Arrangement | 2 Strings |
| Module Dimensions | 2050 × 418 × 3.2 mm |
| Weight | 2.8 kg |
| Front Surface | ETFE |
| Junction Box | IP68 |
| Cable | UV Resistant Solar Cable |
| Connector | MC4 Compatible |
| Parameter | Value |
|---|---|
| Maximum Power (Pmax) | 166.66 W |
| Open Circuit Voltage (Voc) | 26.02 V |
| Short Circuit Current (Isc) | 8.02 A |
| Voltage at Maximum Power (Vmp) | 20.98 V |
| Current at Maximum Power (Imp) | 7.94 A |
| Module Efficiency | 19.45% |
| Power Tolerance | 0 ~ +5 W |
STC: Irradiance 1000W/m², Cell Temperature 25°C, AM1.5
| Parameter | Value |
|---|---|
| NOCT | 45 ± 2°C |
| Temperature Coefficient of Pmax | -0.30 %/°C |
| Temperature Coefficient of Voc | -0.25 %/°C |
| Temperature Coefficient of Isc | +0.046 %/°C |
| Parameter | Value |
|---|---|
| Fire Safety Class | Class C |
| Material & Workmanship Warranty | 5 Years * |
| Power Output Warranty | 15 Years * |
For Non Roofing 2 Years of workmanship and 5 Years on Power output
For roofing 5 Years workmanship and 15 Years on Power Output
